DELEM CNC Control System For Press Brakes

DELEM DA53T Touch Color CNC System

The DA-53T touch CNC control provides a modern compact and versatile solution for a wide range of press brake applications without compromising machine functionality.

10.1" high resolution colour TFT

“Hot-key” touch navigation

Up to 4 axes (Y1,Y2 + 2 aux. axes)

Tool / material / product library

Advanced Y-axis control algorithms for closed-loop as well as open-loop valves.

CNC Crowning control

USB memory stick interfacing

Profile-53TL offline software
preview and download
DELEM DA58T Color 2D graphical CNC System

The DA-58T touch CNC control provides a modern compact and versatile solution for powerful economic press brake applications.

15" high resolution colour TFT

2D graphical touch screen programming

Up to 4 axes (Y1, Y2 + 2 aux. axes)

Bend sequence calculation

Advanced Y-axis control algorithms for closed-loop as well as open-loop valves.

CNC Crowning control

USB, peripheral interfacing

Profile-58TL offline software
preview and download
DELEM DA66T Touch 2D Graphical Control

The DA-66T Touch controls feature the embedded, real-time Windows operating system for maximum reliability. Smooth start-ups ensured, even after instant shut-off.

17" high resolution colour TFT

2D graphical touch screen programming mode

3D visualisation in simulation and production

Full Windows application suite

Delem Modusys compatibility (module scalability and adaptivity)

USB, peripheral interfacing

Profile-T2D offline software

Sensor bending & correction interface
preview and download
DELEM DA69T Touch 3D Graphical Control

The DELEM DA-69T offers 2D as well as 3D programming that includes automatic bend sequence calculation and collision detection. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling.

17" high resolution colour TFT

2D and 3D graphical touch screen programming mode

3D visualisation in simulation and production

Full Windows application suite

Delem Modusys compatibility (module scalability and adaptivity)

USB, peripheral interfacing

Profile-T3D offline software

Sensor bending & correction interface
preview and download

Cybelec CNC Control System

CYBELEC CybTouch 8 PS 2D graphic CNC System

CybTouch 8 PS is intended specifically for synchronized press-brakes.As part of the CybTouch range, it has an intuitive and vivid color touch screen and a high integration of functions.

7” color graphic CRT screen

2D graphic profile creation with manual sequencing

Up to 4 axes (Y1,Y2 + 2-axes)

Bend allowance calculation.

Pressure - crowning calculation.

CNC Crowning control

Angle and back gauge correction.

Delivered with PC1200 offline software.
preview and download
CYBELEC CybTouch 12 PS 2D graphic CNC System

As the entire CybTouch numerical control range, CybTouch 12 PS features an intuitive touch screen user interface, offering a high integration of functions.

12” color graphic with fully touch screen

Touch 2D graphic part creation with manual sequencing

Up to 4 axes (Y1, Y2, X, R-axes)

Bend allowance calculation.

Pressure - crowning calculation.

Modulable tools for each part or bend.

Angle and back gauge correction.

Delivered with PC-ModEva offline software
preview and download
CYBELEC CybTouch 15 PS 2D graphic CNC System

The CybTouch 15 PS is a 2D numerical control specifically dedicated for entry to mid-range CNC press-brakes. It comes in a compact housing, similarly to the well-known CybTouch range in the field, but offering a bigger touchscreen and a new horizontal design.

15” color graphic with fully touch screen

Touch 2D graphical profile drawing and precise 2D program creation

Up to 6 axes (Y1, Y2, X, R, Z1, Z2-axes)

Automatic bending sequence calculation

Tandem management.

Modulable tools for each part or bend.

Angle and back gauge correction.

VisiTouch 2D or VisiTouch MX offline software.
preview and download

ESA CNC Control System

ESA S630 2D Graphical CNC System

The most powerful in its class 10’ touch screen with powerful graphic All the performances of a high-level cnc in an economical and user-friendly controller.

10 inch LCD touch screen (Resistive)

Touch 2D graphic part creation with manual sequence

Stander to 4 axis(Y1, Y2, X, R)

Automatic bending force, crowning calculation.

Modulable tools for each part or bend.

Direct angle correction, also for the crowning.

Proportional and pressure valve Amplify integrated.

Free off-line PC simulation software.

Tandem machine management (option)

Modbus TCP interface for SCADA or MES (option)
ESA S640 2D Graphical CNC System

Top-level performances for machines up to six axes with automatic bending sequence calculations and Material Data Base for predictive compensation are available (as options) to reduce the wastage of material.

15 inch LCD touch screen (Resistive)

Touch 2D graphic part creation with automatic sequence

Stander to 4 axis, can up to 6 axis max.

Automatic bending force, crowning calculation.

Modulable tools for each part or bend.

Direct angle correction, also for the crowning.

Proportional and pressure valve Amplify integrated.

Free off-line PC simulation software.

Tandem machine management(option, can up to 4 machines)

Modbus TCP interface for SCADA or MES (option)
ESA S875 CNC SYSTEM

The CybTouch 15 PS is a 2D numerical control specifically dedicated for entry to mid-range CNC press-brakes. It comes in a compact housing, similarly to the well-known CybTouch range in the field, but offering a bigger touchscreen and a new horizontal design.

21.5” designed for multi touch screen

Support multi touch application

No frame, simple but powerful

Support finger-tip work piece design

Support import of tools shapes (.dxf files)

Support management of tool library

Support tool and die holders' management

Support Datam angle measurement system

Support ESA 3D Bend software

Equip standard industry 4.0 Modbus TCP interface

OPTIONS

The DA-53T touch CNC control provides a modern compact and versatile solution for a wide range of press brake applications without compromising machine functionality.

The DA-58T touch CNC control provides a modern compact and versatile solution for powerful economic press brake applications.

The DA-66T Touch controls feature the embedded, real-time Windows operating system for maximum reliability. Smooth start-ups ensured, even after instant shut-off.

The DELEM DA-69T offers 2D as well as 3D programming that includes automatic bend sequence calculation and collision detection. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling.

CybTouch 8 PS is intended specifically for synchronized press-brakes.As part of the CybTouch range, it has an intuitive and vivid color touch screen and a high integration of functions.

As the entire CybTouch numerical control range, CybTouch 12 PS features an intuitive touch screen user interface, offering a high integration of functions.

The CybTouch 15 PS is a 2D numerical control specifically dedicated for entry to mid-range CNC press-brakes. It comes in a compact housing, similarly to the well-known CybTouch range in the field, but offering a bigger touchscreen and a new horizontal design.

The most powerful in its class 10’ touch screen with powerful graphic All the performances of a high-level cnc in an economical and user-friendly controller.

Top-level performances for machines up to six axes with automatic bending sequence calculations and Material Data Base for predictive compensation are available (as options) to reduce the wastage of material.

The CybTouch 15 PS is a 2D numerical control specifically dedicated for entry to mid-range CNC press-brakes. It comes in a compact housing, similarly to the well-known CybTouch range in the field, but offering a bigger touchscreen and a new horizontal design.
